2. Handling precautions
① Distance between the spry gun and the transmission line : the conventional distance is 150mm-180mm, during the actual operation, plant should adjust the distance according to its own tanning process .
② slurry irrigation pressure : General pressure is within 2.5-3Mpa ,it should be adjusted according to the coating thickness and thin .
③display of remaining slurry : After work ,the slurry should be poured out. Using warm water to push oiled material.,Solvent -based materials should use special solvents to clean it.Setting the computer in cleaning condition until everything is clean enough.
④ Environmental cleanup of spray chamber : water in spray chamber should be changed for once or twice,spray booth should be cleaned every 1-2 days,windows should not be opened very often,or it will affect ventilation effect, but if the pumping power is too large ( spray the little leather) , you can choose opening a window to adjust the degree of the pumping power .
⑤Adjust the number of the slurry: to achieve it by the gun lid knobs, clock-wisely ,it reduces the slurry ,
Counter-clock-wisely, it increases the slurry. plasma volume increases.
⑥ slurry’s atomization area adjustment: adjust the gun side knobs to achieve it.
Precautions of the dust controller
①When spraying leather,dust collector also starts. At the moment, you should use water to watering the dust institutions to prevent dust combustion and pollution of the environment .
② When stop spraying leather, dust collector should continue to work for 15-20 minutes to ensure indoor residual spraying slurry is cleaned.
③ Dust collector is easy to keep dirt : it must be cleaned once every 3-5 days. Methods :open the blower door and eradicate dirt. After cleaning up, put right amount of butter in inner wall and blades.
Keep the work of washing lines:Water in the trough should be changed once everyday. Line brush should be cleaned once a week,(40 ℃ warm water) In addition , depending on the slurry , the line should be washed by warm water or solvent. If using the warm water, the water can be connected to the steam pipe to realize steam heating .
Line is washed clean measure criteria : No lines washed look thicker , if it is not thicker , it is normal .
Temperature control in dryer:it is driven by using temperature sensor to open or close the steam value.Users set the needed temperature o on the thermostat to achieve automatic thermostat .
Lubrication : each bearing parts of the machine should be added oil once a week , reducer must be replaced the oil every six months once.
